98% Accuracy Stainless Steel Pistachio Sorting Machine Separates 8 Grades
  • 98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades
  • 98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades

98% Accuracy Stainless Steel Pistachio Sorting Machine Separates 8 Grades

Place of Origin Hefei China
Brand Name Jinguoyuan
Certification CE Certificate
Model Number LKXG04-2008B
Product Details
Channels:
20
Output:
0.8-1.1 Ton/h
Voltage:
380V
Air Consumption:
5 M3/min
Air Pressure:
>0.6 MPa
Weight:
5980 Kgs
Material:
304 SS
Powered:
Electricity
Highlight:

Stainless Steel Pistachio Sorting Machine

,

Pistachio Sorting Machine 1.1 Ton/H

Product Description

Labor Replacement 98% Accuracy Pistachio Sorting Machine Separates 8 Grades



Product Introduction



Say goodbye to limitations and embrace the versatility of our pistachio sorting machine. Designed to handle all varieties of pistachios, from open and closed to shell, kernel, yellow, black, stain, and husk, our machine adapts to your unique processing requirements. The 8 discharge ports allow for precise grading, ensuring that each pistachio meets the standards of excellence. With a sorting accuracy of more than 98% and a capacity of around 1000kg per hour, experience a sorting solution that opens up new possibilities for your business.



Versatile Sorting for All Pistachios: No Limits, Only Possibilities



98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 0





Material Sorting Effects



98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 1

98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 2







Product Specification





Model LKXG042008B
Lane number 20
Output (t/h) 0.8-1.1
Voltage (V/Hz) 380/50
Power (kW) 7.93
Air Pressure (MPa) >0.6
Air Consumption (m3/mim) 5
Dimension of Main Sorting(mm) 8722*2975*2004
Weight (kg) 5980



Remarks: data takes American pistachios as an example. The output and air consumption change according to state of raw materials, finished materials and channels division. Above data for reference only.



Product Features



  • Automatic feeding system, suitable for mass production
  • 360° material scanning system, high precision industrial cameras
  • Multiple channels & discharges simultaneous with finer sorting
  • Intelligent one-key operation mode, responsive-simplified easy to use

98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 3


Certificates



Quality Management System Certificate, CE Certificate



98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 4

98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 5

98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 6




Packaging & Shipment


98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 7



Warranty



We provide 12 months warranty for our pistachio sorting equipment. In addition, spare and wear parts are available to sent along with the shipment so it's easier to get the equipment at the best working status time and time.



Business Procedures



98% Accuracy Stainless Steel  Pistachio Sorting Machine Separates 8 Grades 8





After Sale Services

  • Professional Installation team & Verification team
  • Perfect operation training before putting into production
  • Free spare & wear parts along with shipment
  • User manuals with operation & maintenance details
  • Quick-response after-sales supports
  • Life-span free software updates​



FAQ



Q: How can I know your equipment suitable for our pistachios or not? Can you send a process video?
A: We accept your pistachios samples and take videos during real processing, so you will have an obvious look at the effect to our dates sorting equipment. In addition, your visit to our manufacturing base is greatly recommended.



Q: What about the lead time?
A: Refer to our business procedures, it will take 15-30 days after contract signed and deposit received, namely after our proposal is agreed to cater your actual demands.
